Reference: Teja-Nature-talón-Manoir-40-50

Nature Tile Heel Manoir 50 x 20.5 cm

Tejas Borja
Before: €2.27
-5%
Tax included at 21%
Share
Share
Receive it between 12 and November 16.

Calculate your shipping costs

Select zone and quantity

The Nature Manoir 50/45 Tile features a unique design with support heels on its lower face, making it perfect for installation in the channel position. In addition, it comes equipped with a pre-marked hole for secure attachment through nails or screws in the batten.

With this tile, you can be sure of effective weather protection and a long service life for your roof.

Questions? Message us on WhatsApp

Complementary items:

Nature Heel Serrania Tile 50 x 20.5 cm €2.16 Nature Heel Speckled Tile 50 x 20.5 cm €1.99 Nature Heel Tile 50 x 20.5 cm €1.87

The Nature Manoir 50/45 Tile is an essential solution to guarantee efficient water evacuation on roofs with large curved tiles, such as C-50.21 Celler® and C-45.20. With a length of 50 cm and a variable width from 20.5 cm to 16.5 cm, these tiles offer a versatile and practical design. Its weight of 2.50 Kg per unit and its capacity of 10 tiles per square meter, together with 10 Celler® 50x21 tiles, ensure a solid structure for your roof.

The useful length of 35 to 40 cm provides flexibility in installation, while the 4 tiles per linear meter in the eave, and 2.5 tiles per linear meter in the ridge and side, allow a safe and efficient assembly. With a maximum overlap of 17.0 cm and a minimum overlap of 8.0 cm, these tiles offer an optimal fit range.

For installation, a metal batten or treated wood support is recommended. Dry fixing can be done by screws or nails, depending on the type of support chosen. Providing flexibility to adapt to your project needs.

Product Nature Tile Heel Manoir 50 x 20.5 cm
Brand / Manufacturer Tejas Borja
Weight (kg) 2.5 kg/tile
Width (cm) 20.5 / 16.5
Length (cm) 50
Units/m2 10
Maximum Overlap (cm) 17
Minimum Overlap (cm) 8
